Ultra-rugged wired tracking built for the harshest environments.

The Armour Type 1 is a heavy-duty, high-performance GPS tracker designed for demanding fleet, vehicle, trailer, and equipment monitoring. Wire it directly into power for continuous real-time tracking, with a large internal backup battery and advanced I/O options for comprehensive control and insights.

Engineered for tough Australian conditions — construction, mining, agriculture, and heavy machinery — the Armour Type 1 delivers reliability where other trackers fail.

Key Features:

• High-Precision GNSS Tracking — Concurrent GPS, GLONASS, Galileo & BeiDou for ~1.5–2m accuracy with excellent sensitivity and cell tower fallback.
• Bluetooth® Gateway (BLE 5.2) — Scans and reports on BLE tags, wireless sensors, and supports Driver ID for enhanced asset and operator monitoring.
• Flexible Inputs & Outputs — 1 x Ignition, 3 x Digital Inputs, 1 x Analog Input, 1 x Switched Ground Output, plus switched power out — perfect for PTO monitoring, door sensors, panic buttons, lights, buzzers, and more.
• Large Backup Battery — 1100mAh LiPo internal battery for extended operation and instant power-loss/tamper alerts.
• Advanced Safety & Control — Accident/rollover detection, harsh driving behaviour (acceleration, braking, cornering), speeding, geofencing, run hour monitoring, and remote immobilisation capability.
• Ultra-Rugged Design — IP68 & IK08 rated waterproof, dustproof, and impact-resistant housing. Load-dump and short-circuit protected for harsh automotive environments. Non-branded housing ideal for white-labeling.
• 4G LTE-M / NB-IoT Connectivity — Reliable low-power global cellular coverage with AES-256 encryption and remote configuration.

Ideal For: Heavy equipment & machinery tracking, fleet management, trailers, excavators, trucks, mining & construction assets, driver safety programs, theft recovery, and remote immobilisation. Built tough for maximum uptime in extreme conditions.

Technical Specifications:

• Dimensions: 126 × 80 × 27 mm
• Weight: Robust compact build
• Operating Temperature: -30°C to +60°C
• Power: 8-33V DC (wired) with 1100mAh LiPo backup battery
• Warranty: 2 Years
